BRICK S
BRICK S
Brick S modules are combined in TETRIS S cabinet creating the required power.
Each Brick S module has a plug and play connector for an easy connection with Tetris S cabinet. Each module is composed by a cylindrical three-phase capacitor (nitrogen or resin filling), fuses and contactor for capacitive loads insertion.
For Brick S module type “AC” there are also detuning reactors at 189Hz (other detuning factor on request) and a ventilation system.
Technical data sheet for module Brick S, capacitor with nitrogen filling at 415V
Technical data sheet for module Brick S, capacitor with nitrogen filling at 440V
Technical data sheet for module Brick S, capacitor with resin filling at 415V
Technical data sheet for module Brick S, capacitor with resin filling at 450V
